The Leak Stereo 230 is a top-of-the-line integrated amplifier that delivers high-performance sound and style. With 115 watts per channel and a range of input options, it's perfect for modern audio and movie enthusiasts. The Stereo 230 also boasts a newly developed HDMI ARC function for top-quality audio in AV applications.
Connect your turntable, digital sources, or stream music via Bluetooth with the Stereo 230's built-in phono pre-amplifier and aptX and AAC codecs. We've made sure the digital circuitry in this amplifier delivers the same level of quality you'd expect from a standalone D/A converter.
In addition to its excellent performance, the Stereo 230 is designed with reliability and craftsmanship in mind. It combines contemporary performance with classic Leak styling to make it a standout piece in any setup.
Experience exceptional sound quality with the included high-quality, low-noise turntable input optimized for moving magnet cartridges. The JFET-based circuit offers precise RIAA equalization, meeting industry standards for the best vinyl record playback.
Get the same performance as standalone headphone amplifiers, but at a lower price point with the dedicated amplifier circuit and current-feedback technology included for the headphone output. The high slew rate allows for exceptional output signal transitions, delivering a dynamic, detailed, and engaging performance with all types of headphones.
Enjoy ultra-low noise and high dynamic range of digital audio files with the included acclaimed ES9038Q2M Reference chip and ESS Technology's 32-bit HyperStream architecture with Time Domain Jitter Eliminator. The sampling rate goes up to a breathtaking 768kHz (PCM) and DSD512.
The included Audio Return Channel (ARC) connection makes this amplifier perfect for home AV applications, bringing the LEAK Hi-Fi pedigree to your screen as well.
D/A Converter: | ES9038Q2M 32-bit DAC |
---|---|
Input Sampling Rates: | Optical/Coaxial: 44.1kHz~192kHz PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD512 |
Rated Output Power: | 2 x 75W (8ohm) / 2 x 115W (4ohm) Class AB |
Total Harmonic Distortion: | <0.003% (1kHz @30W/8ohm) |
Frequency Response: | 20Hz-20kHz (+/-0.3dB) |
Input Sensitivity: | 480mV (RCA AUX IN); 4.1mV (phono MM) |
Input Impedance: | 10Kohm (AUX) ; 47Kohm //100pF (phono MM) |
Signal to Noise Ratio: | ≥109dB (A-weighted, ref.45W) |
Bluetooth: | A2DP, aptX (priority), SBC |
USB Input: | 1 x USB (B-type) |
Digital Audio Inputs: | 2 x Optical TOSlink ,1 x RCA COAX |
Digital Audio Outputs: | 1 x Optical TOSlink ,1 x RCA COAX |
Analog Inputs: | 2 x RCA (AUX1, AUX2) ,1 x RCA (phono MM) |
Analog Output: | 1 x RCA (PRE OUT) |
Power Requirement: | 100-120V ~ 50/60Hz |
Dimensions (W x H x D): | 12.83" x 5.74" x 16.2" |
Weight: | 28 lbs |
Shipping Dimensions (W x H x D): | 20.2" x 8.2" x 16.8" |
Shipping Weight: | 33.5 lbs |
